Good news: Lanxing Technology's invention patent was successfully implemented

As one of the drafting units of the national standard, Lanxing Technology has industry-leading R&D capabilities. In 2019, it took the lead in launching the most advanced LX-P series ranch electronic fence host in the livestock industry, and broke through the industry ceiling to develop pulse synchronization technology. In the same year, it applied for an invention patent. After 5 years, the invention patent has finally landed, which is not easy.

Name: An energy control system for energy multiplication

As early as the beginning of the 20th century, Europe began to have pulse electric fences. With the rapid development of its animal husbandry industry, their electronic fence hosts have gradually failed to keep up with the expansion. To put it bluntly, the perimeter length that a single host can manage is limited. If the key components are simply enlarged, the cost will increase exponentially. It is better to buy another host for the new expansion area. Lanxing Technology also entered this industry with the products of European countries in the early days. In 2009, it launched the first domestic ranch electronic fence host dedicated to the livestock industry. However, in the process of use in recent years, the problems encountered by European countries have gradually manifested themselves in China. Therefore, the LX-P series ranch electronic fence host took various factors into consideration during the research and development design stage, and specially added a pulse synchronization technology.

What is pulse synchronization technology, and how can it make energy superimposed?

Pulse synchronization technology, in principle, uses connecting wires to make multiple host pulse outputs simultaneously generate high voltage outputs to an external network environment, so that the effect of 1+1=2 can be achieved. For example, if a 5J host is added to a 2J host, after pulse synchronization, the energy delivered to the external network is 5J+2J=7J. Up to 9 hosts are supported for pulse synchronization.

The use of pulse synchronization technology can make the perimeter defense distance farther and do more things with lower costs. At the same time, the perimeter management is more flexible, and the devices can be combined to form a larger range, or used alone to form a small perimeter. Moreover, the perimeter length of the LX-P series ranch electronic fence host is not small, and the perimeter length is also added after pulse synchronization. You can refer to the table below, the LX-P series ranch electronic fence host model parameter table:

In addition to pulse synchronization technology, the LX-P series ranch electronic fence has more special features.

Power supply

LX-P power supply has 3 power supply modes: adapter, solar energy, battery

Application environment

The host can be used in harsh environments, and the shell is IP55 waterproof

Its special functions

General alarm: short circuit, disconnection, battery undervoltage

6-level LED dynamic indication of high voltage output voltage or power supply battery voltage

LCD display screen

Displays various parameters

Pulse cycle adjustable

2.5S large cycle, 1.5S small cycle, daytime, nighttime and other working modes

Multiple back binding methods

Adapt to various installation environments

GPS positioning + mobile phone control

With positioning function, alarm will be issued immediately when leaving the designated area

Mini program control function
