Power supply: 802.3af (PoE), DC12V/2A.
Use environment: temperature: -25℃~+55℃, humidity: ≤95%.
Communication method: TCP/IP, RS485, power communication (depending on the specific model).
Backup battery: DC12V/4AH lead-acid battery (need to be purchased separately).
Casing material: ASA.
IP level: IP55.
Alarm type: short circuit, wire break, anti-cut, network contact, anti-disassembly, power failure, fault, communication failure.
Pulse output characteristics:
Single-line pulse output peak: high voltage: 4KV-7KV low voltage: 0.6KV-1.5KV.
Pulse output peak current: ≤10A Output duration exceeding 300ma ≤1.5ms.
Pulse duration: ≤0.1S Pulse interval time: 1.0S-1.6S.
Maximum power output of a single pulse: 2.5mc.
Maximum energy output of a single pulse: 5.0J.
Rated power of the whole machine: ≤15W.
Note: Adding remote control function (standard 1 remote control module and 2 remote controllers) will increase the price by 100 yuan per unit.
Adding POE module will increase the price by 100 yuan per unit.
